Radial HotShot MD Dynamic Microphone Switcher with Noise free Switching and Ground Lifts

Call The Shots From One Mic
The Radial HotShot MD gives music directors and artists easy and discreet control over their microphone outputs to enable seamless transitions between singing, cueing the band, and coordinating with techs and engineers—all without disrupting the audience experience. Engineered with Radial’s signature road-ready construction and noise-free switching, the HotShot MD streamlines communication, boosts efficiency, and enables bandleaders to focus on delivering flawless performances.

3 Channels of Discreet Onstage Communication
A noise-free solution for momentarily rerouting a dynamic microphone on stage, the HostShot MD allows signal to pass through Output-A when no footswitches are depressed, so your vocal mic feeds the PA system normally. If either the B or C footswitches are engaged singly, Output-A will be muted, and signal will be diverted to Output-B or Output-C, depending on which footswitch is depressed. This allows you to instantly reroute your mic to speak with band members or technicians as needed without the audience hearing a thing. Both footswitches can also be engaged simultaneously, so you can communicate with all parties at once. The moment you release either footswitch, your vocal mic automatically redirects back to the PA system so the performance can continue.

Using MD for silent communication on stage
Plug your mic into the HotShot MD and connect output-A to the PA system. Plug outputs B and C to separate channels on the monitor desk. When you press & hold footswitch B, C, or both simultaneously, the PA system output is muted, and the signal goes to the band, tech team, or both, respectively.

Using the MD as a cough mute
Sometimes, you just have to cough. Connect your mic to the HotShot MD input, Output-A to the audio system, Output B to the monitor console for band communication, and leave Output-C disconnected. When the urge to cough or the need to mute the system occurs, simply depress and hold footswitch C. Let go to revert to normal operation.

Using the MD to add effects
Like the HotShot DM-1, the HotShot MD is a great way to add effects to your vocal. However, the HotShot MD allows you to apply two separate channels of effects and combine them as desired. Channels B and C can be set to trigger effects such as echo and delay, respectively. Just hold the corresponding foot switch down to engage an effect or both footswitches to use the effects in tandem. Simply release the switch to go back to normal.

Radial HotShot MD Features :

• Dynamic mic switcher for onstage communication systems during live performances and rehearsals

• Adjust for your needs with multiple configuration possibilities

• B/C momentary footswitches divert audio immediately when pressed and depressed

• Seamless transitioning between main sends and B/C sends

• 100% passive design no external power required

• 14-gauge steel enclosure protects on any stage

• Ground lifts eliminate pesky hums or ground loops

Radial HotShot MD Technical Specifications

• Type : Dynamic Mic Switcher

• Inputs : 1 x XLR

• Outputs : 3 x XLR

• Power Source : Passive

• Height : 2"

• Width : 4.63"

• Depth : 3.70"

• Weight : 1.4 lbs.

• Manufacturer Part Number : R800 1501 00
